Event Video Player (EVP380)

All-in-one show control player for synchronising sound, image and light.

  • Synchronised 4K HDR10 audio/video playback with DMX512, RS-232 and relay control
  • Interactive HTML5 interfaces thanks to integrated JavaScript engine
  • Record and playback Art-Net or DMX512 scenes from any console
  • Multiple triggers: contacts, clock, TCP/IP, HTTP, DMX, touchscreen
  • Compatible with PIXILAB Blocks®
  • Integrated line and amplified audio outputs for simplified installation
  • Quick installation: 1U rack format, plug-in connectors
  • 24/7 reliability, designed and manufactured in France, 3-year warranty

Download the datasheet



Description
Applications
Specifications
Description

All-in-one show control player for your immersive installations

The Event Video Player is a complete audio/video broadcast solution synchronised with show control. It controls lights, relays and serial equipment (RS-232) in perfect coordination with your 4K HDR10 content.

Create interactive experiences thanks to its HTML5/JavaScript engine: develop your own custom graphical interfaces and connect your scenarios via the control APIs.

Powerful and flexible audiovisual broadcasting

  • Video playback up to 4K HDR10, with perfect synchronisation with lighting effects.
  • Line and amplified audio outputs for speakers: adapt to all types of environments.
  • Dynamic interfaces: enrich the user experience with interactive HTML5 pages.

Intelligent, versatile show control

  • Automatically triggered on power-up.
  • Detection and action via contact inputs/outputs, Art-Net, DMX512, TCP/IP, HTTP or serial link.
  • Integrated multi-touch screen for direct interaction with visitors.
  • Integrated timetabling for scheduled, unsupervised broadcasts.

Wavespark: your audio, video and lighting supervision solution

logo wavespark par waves system

  • Manage and update your players remotely from a simple, centralised web interface.
  • Synchronise your interactive content (video, sound, lighting, sensors, etc.) and deploy powerful immersive experiences.
  • Wavespark is the ideal solution for controlling your scenarios and keeping your fleet of players up to date, whatever the sector: fitness, catering, health or museography.

Simplified scheduling and custom creation

  • Record your scenes directly from a console or software via Art-Net or DMX512.
  • Create and edit your show controls with the Show Control Editor software.
  • Display your interfaces on an external screen for audiences or technical teams.

Designed to last and integrate easily

  • Reliable 24/7 operation.
  • French design and manufacture, 3-year warranty.
  • Rack-mountable format and plug-in connectors for quick, clean installation.
  • Direct access to storage for simple, efficient updates.

Where is the EVP380 show control player used?

Theme parks and escape games

A complete solution for synchronised show management: sound, lighting, video, effects.
Create immersive experiences triggered automatically or on demand.
Easily script each stage of the journey using a range of trigger modes.

Heritage sites and night-time itineraries

Liven up your light shows, Christmas shows or guided tours with precision.
Synchronise music, projections and lighting, even outdoors or in offline mode.
Plan your sequences by calendar or via a simple web interface.

Sports halls and immersive fitness studios

Create powerful environments by synchronising video, audio and dynamic lighting.
Control each session by time, coach or programme intensity.
Touch interface and easy integration with existing equipment.

Retail and flagships

Bring your point of sale to life with made-to-measure audiovisual theatrics.
Synchronise windows, lighting, music and screens according to the highlights of your marketing strategy.
Control all content remotely for harmonised communication.

Audiovisual integrators and design offices

A robust, open and flexible platform designed for complex projects.
Crestron®, Control4® and PIXILAB Blocks® compatible, with JavaScript API and serial control.

Audio

  • Unbalanced line-level stereo audio output on standard RCA connectors
  • Class D amplified stereo speaker audio output on 3.81 mm plug-in terminals
  • Audio amplifiers:
    • 2 × 8 W – 8 Ω, THD+N = 1%, 1 kHz
    • 2 × 10 W – 8 Ω, THD+N = 10 %, 1 kHz
    • 2 × 15 W – 4 Ω, THD+N = 1%, 1 kHz
    • 2 × 19 W – 4 Ω, THD+N = 10 %, 1 kHz
  • Audio formats supported: WAV, MP3, OGG, OPUS, M4A, MKA
  • Audio codecs:
    • LPCM: up to 8 channels, 16/24-bit, up to 96kHz
    • MP3: MPEG-1/2 Audio Layer III, mono/stereo, up to 48kHz, CBR/VBR
    • AAC-LC: up to 8 channels, up to 96kHz
    • HE-AAC-LC: mono/stereo, up to 96kHz
    • Vorbis: up to 8 channels, up to 96kHz
    • Opus: up to 8 channels, up to 48kHz
    • FLAC: up to 8 channels, 16/24-bit, up to 96kHz
    • DTS: HDMI passthrough
    • AC3 Dolby Digital: HDMI passthrough or up to 6 channels, up to 48kHz
    • E-AC3 Dolby Digital+: passthrough HDMI

Video

  • HDMI audio/video output on Type-A connector (HDMI 2.0b, HDR10 and CEC)
  • Standard video formats supported:
    • Ultra HD 4K (3840 × 2160), 24/25/30/50/60 Hz
    • 1080p (1920 × 1080), 24/50/60 Hz
    • 1080i (1920 × 1080), 50/60 Hz
    • 720p (1280 × 720), 50/60 Hz
    • 576p and 576i (720 × 576), 50 Hz
    • 480p and 480i (720 × 480), 60 Hz
  • VESA progressive scan resolutions:

Hauteur ↓ / Largeur →640800852854102411521280136013661400144016001680192021602560
48060 Hz60 Hz60 Hz60 Hz
60060 Hz60 Hz
76860 Hz60 Hz60 Hz60 Hz
80060 Hz
86475 Hz
90060 Hz60 Hz
96060 Hz
102460 Hz
105060 Hz60 Hz
120060 Hz60 Hz90 Hz
160060 Hz
  • Dynamic range: HDR10 compatible
  • Video codecs:
    • H.265 HEVC MP-10@L5.1 up to 4K×2K@60fps
    • VP9 Profile-2 up to 4K×2K@60fps
    • H.264 AVC HP@L5.1 up to 1080p@60fps and 4K×2K@30fps
  • Container formats: MP4 (MPEG-4), MKV (Matroska), MOV (QuickTime)
  • Image formats: JPEG (ISO/IEC-10918), PNG, BMP
  • Subtitle formats: SRT (SubRip), SSA (SubStation Alpha), ASS (Advanced SubStation Alpha), VTT (WebVTT), TTML (Timed Text Markup Language), DFXP (Distribution Format Exchange Profile)

Simplified remote management

  • Easily monitor your players and accounts from a single location.
  • Configure and control your players remotely while updating your content in real time.
  • Manage your media library, create personalised playlists
  • schedule the delivery of your content for optimal, synchronised viewing.
  • Embedded web server for HTML5/JavaScript pages
  • Remote administration: configuration, control, content updates, maintenance
  • REST API for player control
  • PJLink server for projector control
  • FTP server for remote content updates
  • TCP/IP server for player control
  • Art-Net 3
  • NTP client for clock synchronisation
  • IPv4 (static or DHCP) and IPv6
  • mDNS identification service (Zeroconf)
  • Synchronised triggering of multicast playback in UDP

Show Control

  • Playback and recording of show control files:
    • Up to 64 Art-Net universes
    • One DMX512 universe
    • 8 contact outputs
    • Serial frame sending
  • Real-time DMX preview mode
  • Art-Net/DMX512 node to fixture control (14 channels):
    • Playback controls (3 channels)
    • Contact output control (8 channels)
    • Sending serial frames (2 channels)
  • Art-Net/DMX512 node to DMX512 output
  • Configurable recording control conditions:
    • First packet received (start)
    • Countdown (start)
    • Control channel (start/stop)
    • End of media playback (stop)
    • Recording time elapsed (stop)
    • On user request (stop)
  • Show delay configurable from 0 to 2000 ms
  • Embedded web browser based on Chromium v92.0.4515.159
  • JavaScript API for player control
  • Web page resolution: 1920×1080
  • Specific file formats:
    • SC3 (.sc3): show control file in ‘Show Control V3’ format
    • TM2 (.tm2): scheduler.tm2 file in ‘Scheduler V2’ format
    • TXT (.txt): text files for the serial link (serial.txt) and FTP configuration (ftpset.txt)

Interfacing and connectivity

  • Backlit LCD display – 2 × 16 characters
  • Status LED
  • Click wheel (volume/system information)
  • Infrared sensor – Protocol: NEC
  • 2 USB 2.0 High Speed (480 Mb/s) host connectors, type-A, compatible:
    • USB Mass Storage
    • USB HID mouse, keyboard and multi-touch screen
    • USB Audio Class 2.0
  • Ethernet 10/100 Mb/s, RJ45 connector
  • DMX512 output on XLR3 female connector, with isolation
  • DMX512 input on XLR3 male connector, with isolation, built-in switchable 120 Ω termination, switchable pass-through to DMX512 output
  • 1 stand-alone optocoupled input contact on 3.81 mm plug-in terminal block (typical anti-bounce time: 25 ms)
  • 8 optocoupled combined input contacts on 3.81 mm plug-in terminal block (typical anti-bounce time: 25 ms)
  • 8 MOSFET outputs (500 mA per output, max 20 V) on 3.81 mm plug-in terminal block
  • RS-232 serial link on 3.81 mm plug-in terminal block (1200, 2400, 4800, 9600, 19200, 38400, 57600 or 115200 bauds)
  • 4 power supply outputs on 3.81 mm plug-in terminals
  • 5 V DC (500 mA) power supply output on 3.81 mm plug-in terminal block
  • External DC power connector – Socket: Ø 2.1 mm / 5.5 mm

Storage device

  • Internal storage: 4 GB
  • microSD card slot
  • Supported media types:
    • microSDSC/SDHC/SDXC cards
    • USB memory sticks
  • Supported file systems:
    • FAT32 (read/write)
    • exFAT (read/write)
    • NTFS (read/write)
    • ext2/3/4 (read/write)

General information

  • Power input: 12 V DC – 3.45 A
  • Mains adapter supplied: 100-240 V, 50-60 Hz
  • Current consumption (at 12 V):
    • Typical consumption when reading from internal memory: 500 mA
    • Recommended power supply for full use: 3.45 A
  • On-board clock (battery life without power: up to 2 months)
  • Dimensions: 140 mm × 43 mm × 136 mm (1/3 19’ rack – 1U)
  • Weight: 446 g (with plug-in terminals)
  • Operating temperature: 0 to +45 °C
  • Storage temperature: -20 to +60 °C

All-in-one show control/audio/video player

The Event Video Player offers a unique and complete show control solution (DMX512 output, contact outputs and RS-232 commands) in perfect synchronization with audio/video playback up to 4K HDR10 resolution.

With the HTML5/JavaScript engine enrich your video content with dynamic graphical interfaces.

The player has line and amplified audio outputs for speakers suitable for all types of installations.

Multiple triggers and scenarios

Your scenarios can be run through numerous interfaces: automatic playback on power-up, contact inputs and outputs, Art-Net or DMX512 commands, multi-touch screen, TCP/IP or HTTP commands, serial link, time programming.

Go further, develop your HTML applications by integrating the player’s JavaScript control APIs, remote interface used by the public.

Reliable and easy to install

The Event Video Player is designed for 24/7 operation. Designed and manufactured in France, it comes with a 3-year warranty.

Record directly the show controls in Art-Net or DMX512 from your console or your usual software, or create them from the dedicated Show Control Editor software.

The installation of an Event Video Player is quick and easy thanks to its plug-in connectors and its rack-mountable format. Direct access to content makes updates quick and intuitive.
